Productdetails:
|
| INDUCTANTIE: | 4.7 uH | Gevalcode - mm: | 4040 |
|---|---|---|---|
| Pakket / Geval:: | 1616 (metrische 4040) | Maximumgelijkstroom-Stroom: | 5.1A |
| Productkenmerk | Kenmerkwaarde |
|---|---|
| Coilcraft | |
| Productcategorie: | Machtsinductors - SMD |
| RoHS: | Details |
| Machtsvernauwing | |
| SMD/SMT | |
| 1616 (metrische 4040) | |
| Beschermd | |
| 4.7 uH | |
| 20% | |
| 5.1 A | |
| 44.1 mOhms | |
| 4.5 A | |
| - 40 C | |
| + 125 C | |
| - | |
| PCB zetten op | |
| 4 mm | |
| 4 mm | |
| 3,1 mm | |
| - | |
| Samengesteld | |
| Aec-Q200 | |
| XAL4030 | |
| Spoel | |
| Besnoeiingsband | |
| Spoel | |
| Toepassing: | Automobiel |
| Merk: | Coilcraft |
| Gevalcode - in: | 1616 |
| Gevalcode - mm: | 4040 |
| Product: | Machtsinductors |
| Producttype: | Vaste Inductors |
| Zelf Resonerende Frequentie: | 36 Mhz |
| 500 | |
| Subcategorie: | Inductors, Vernauwingen & Rollen |
| Beëindiging: | Norm |
| Testfrequentie: | 1 Mhz |
| Deel # Aliassen: | XAL4030-472MEB |
| Eenheidsgewicht: | 0,003069 oz |
| Artikelnummer 1 | Inductantie (µH) 2 (Tolerantie: ±20%) |
DCR (mΩ) 3 | SRF-type (Mhz) 4 | Isat (a) 5 | Irms (a) 6 | ||
|---|---|---|---|---|---|---|---|
| type | maximum | 20°C-stijging | 40°C-stijging | ||||
| XAL4020-221ME_ | 0,22 | 5.8 | 6.4 | 191 | 18.7 | 12.0 | 16.8 |
| XAL4020-401ME_ | 0,40 | 7.6 | 8.3 | 145 | 12.5 | 10.0 | 14.0 |
| XAL4020-601ME_ | 0,60 | 9.5 | 10.5 | 106 | 10.4 | 7.9 | 11.7 |
| XAL4020-102ME_ | 1.0 | 13.3 | 14.6 | 79.0 | 8.7 | 6.7 | 9.6 |
| XAL4020-122ME_ | 1.2 | 17.8 | 19.5 | 69.0 | 7.9 | 6.6 | 9.0 |
| XAL4020-152ME_ | 1.5 | 21.5 | 23.6 | 64.0 | 7.1 | 5.2 | 7.5 |
| XAL4020-222ME_ | 2.2 | 35.2 | 38.7 | 52.0 | 5.6 | 4.0 | 5.5 |
| XAL4030-332ME_ | 3.3 | 26.0 | 28.6 | 43.0 | 5.9 | 5.0 | 6.6 |
| XAL4030-472ME_ | 4.7 | 40.1 | 44.1 | 36.0 | 4.6 | 3.9 | 5.1 |
| XAL4030-682ME_ | 6.8 | 67.4 | 74.1 | 29.0 | 3.6 | 3.0 | 3.9 |
| XAL4040-822ME_ | 8.2 | 60.8 | 66.9 | 27.0 | 4.0 | 2.4 | 3.4 |
| XAL4040-103ME_ | 10 | 84.0 | 92.4 | 24.0 | 3.0 | 2.2 | 3.1 |
| XAL4040-153ME_ | 15 | 109 | 120 | 20.0 | 2.9 | 2.0 | 2.8 |
